Boston Dynamics Spot

Photo © Boston Dynamics · product page

Boston Dynamics

Boston Dynamics Spot

Quadruped
Height
610 mm
Mass
32.7 kg
Max speed
1.6 m/sLowest of 16 in this category
Runtime
1.5 h90 min as published
Battery capacity
564 WhLowest of 8 in this category
  • Stair capable
  • IP54
  • Open API
  • Teleoperation

15 figures from 1 published document on bostondynamics.com, each linked to the line it came from

View on the maker’s sitebostondynamics.comManufacturer documentspecifications

Specifications

Physical

Mass32.7 kgBoston Dynamics
Height610 mmBoston Dynamics

Motion

Max speed1.6 m/sBoston Dynamics
Max slope30°Boston Dynamics
Max step height300 mmBoston Dynamics
Stair capableYesBoston Dynamics

Power

Battery capacity564 WhBoston Dynamics
Runtime5,400 s90 min as publishedBoston Dynamics

Environment

IP ratingIP54Boston Dynamics
Min operating temp-20°CBoston Dynamics
Max operating temp55°CBoston Dynamics

Safety

Safety standardsISO 12100, IEC 60204-1, ISO 13850, FCC Part 15B, FCC Part 68, IEC 60825-1:2007 & 2014, cTUVus (UL 1564, CSA C22.2 No. 107.2)Boston Dynamics

Software

Open APIYesBoston Dynamics
TeleoperationYesBoston Dynamics

Commercial

Warranty12 monthsBoston Dynamics
